Model |
Single layer heating: BC-1908E1-HT / Dual layer heating: BC-1908E2-HT |
Printhead Type |
EPSON 13200-A1 |
Printhead Quantity |
8 |
Printing Speed |
1Pass 360*1200DPI 300m2/H , 2Pass 360*2400DPI 150m2/H |
Printing Width |
1900mm |
Ink Type |
Sublimation Ink |
Ink Capacity |
4*5L |
Color Mode |
K CMY(8 color optional) |
Media |
Sublimation Paper |
RIP Software |
Maintop 6.1/ Photoprint / Neostampa(Optional) |
PC System |
Win 7 64bit , Win 10 64bit |
PC Requirements |
W7 or above, 64 bit, CPU Processor i5 or above, 8G Storage, C disk with solid state hard drive 120G or above Attached disk 1TB, Gigabit Ethernet port |
File Format |
TIF / JPG |
Working Condition |
Temperature: 18-28C , Huridity: 50+10% |
Take Up System |
Automatic feeding and collecting system |
Drying System |
Automatically drying the surface |
Input Voltage |
AC220V~250V 50/60H |
Power Consumption |
Printer: 1.5KW,Drying / Heating: 7.2KW |
Advantages |
Automatic cleaning: Automatic ink-leakage alarming; Automatic spraying |
Printer Size |
Printer:L3200mm*W700mm*H810mm , Base:L2400mm*W850mm*H950mm |
Packing Size |
Printer:L3360mm*W850*1110mm +Base:L2710mm*W1000mm*H1050mm (Two wooden box) |
Net Weight |
550KG |
Gross Weight |
411KG(Printer) 368KG(Base) |
