Model |
LN-1802FA |
LN-1804FA |
Printhead Type |
2 |
4 |
Printhead Quantity |
EPSON 13200-E1 |
|
Printing Speed |
4Pass360*2400DPI 32m2/H |
4Pass(4H)360*2400DPI 65m2/H |
6Pass720*1800DPI 21m2/H |
6Pass(3H)720*1800DPI 34m2/H |
8Pass720*2400DPI 16m2/H |
8Pass(4H)720*2400DP 32m2/H |
Printing Width |
1800mm |
Printing Height |
2mm |
Ink Type |
Leather Ink (Eco) |
Ink Supply method |
Positive pressure ink supply |
Ink Capacity |
5L (4-Color) |
Color Mode |
4-Color:KCMY / 8-Color: KCMY+LLK+LK+LC+LM(optional) |
RIP Software |
Maintop 6.1 |
Transfer Method |
Gigabit Ethernet port |
PC Requirements |
W7 or above, 64 bit,CPU Processor i5 or above, 8G Storage, C disk with solid state hard drive 120G or above.Attached disk 1TB, Gigabit Ethernet port |
File Format |
TIF (CMYK) |
Working Condition |
Temperature:20-28°C , Humidity : 45-65% |
Media Transfer |
High strength conveyor belt |
Drying Method |
External drying system |
Input Voltage |
220V、110V (customizable) |
Power Consumption |
Blower 1500W,Printer 1500W, External drying system 4000W |
Printer Size |
L3300mm*W1600mm*H1460mm |
Packing Size |
L3400mm*W1300mm*H1590mm |
Net / Gross Weight |
850KG/1050KG |
