| Model | CL-0604UH | |
| Printhead Type | EPSON I3200-U1 | |
| Printhead Quantity | 4 | |
| Printing speed | UV DTF gold stamping process : 8pass 5.5m2/h ; 12Pass 3.5m2/h |
UV DTF stamping process : 6pass 7m2/h ; 8Pass 5.5m2/h ; 12Pass 3.5m2/h |
| Color Mode | UV DTF printing process : KCMY+W+V(varnish)+G(Hot stampingvarnish) |
UV DTF printing process: KCMY+W+V(varnish) |
| Ink Type | UV DTF Ink | |
| Printing width | 590mm(Maximum film width: 620mm) | |
| Material Type | Gold stampingA film, Drainning film. Gold stamping foil, Gold stamping transfer film |
UV DTF A film & B film |
| Curing System | UV LED lamp | |
| File Format | TIF/PNG ( Mode:C M Y K ) | |
| RIP Software | PO-TRY/Maintop 6.1 (UV version)/Photoptit (optional) | |
| Power Consumption | 5000W | |
| Input Voltage | AC220V士10%,50/60Hz,AC110V (optional) | |
| Working Condition | Temperature: 20-28°c,Humidity: 45-65% | |
| Printer Size | L1900mm*W1000mm*H1600mm | |
| Net Weight | 380KG | |
| PC Requirements | Win7 or above, 64 bit, CPU Processor i5 or above, 8G Storage, Cdisk with solid state hard drive 120G or above,Attached disk 1TB, Gigabit Ethernet port | |
| Square number of power cords used by the machine | 4m² | |
