| Model | CL-0303XH | CL-0302LH |
| Printhead Type | F1080-A1 | 11600-U1 |
| Printhead Quantity | 3 | 2 |
| Printhead Speed | 6pass 720*1080DPI 3.2m2/h | 6pass 720*900DPI 2m2/h |
| 8pass 720*1440DPI 2.5m2/h | 8pass 720*1200DPI 1.45m2/h | |
| Color Mode | K C M Y + W + Varnish | |
| Ink Type | UV DTFInk | |
| Printing Width | 290mm(Maximum film width:310mm) | |
| Material Type | UV DTF A &B film, gold film, silver film | |
| Curing System | UV LED lamp(air-cooled) | |
| File Format | TIF(CMYK) | |
| RIP Software | Maintop 6.1(UV Version)/ Photoprint | Maintop 6.1(UV Version) |
| Power Consumption | Heat roller:500W/Machine: 650W | |
| Input Voltage | AC220V +10%.50/601HzAC110V(optional) | |
| Working Condition | Temperature:20-28°C,Humidity:45-65% | |
| PC Requirements | Win7 or above, 64 bit, CPU Processor i5 or above, 8G Storage, C disk with solid state hard drive 120G or above, Attached disk 1TB, Gigabit Ethernet port | |
| Printer Size | L1150*W670*H530mm(Base notincluded) / L1170*W870*H1030mm(Baseincluded) | |
| Packing Size | L1220*W750*H660mm | |
| Net Weight | 80KG(Base not included,base 19kg) | |
| Gross Weight | 125KG (Including base) | |
